PLCs and drives get software and component upgrade with retrofit kit

March 29, 2021
Technology conversion gets tested in manufacturing plant before successful rollout out to satellite lines

From its early beginnings, the Krispy Kreme company has designed and built the proprietary machines that have given rise to their equally safeguarded doughnut recipe. The quality and consistency of the global doughnut brand starts at the company’s headquarters in Winston Salem, North Carolina. where a 105,000-sq-ft manufacturing facility houses research, design, testing, engineering and production.

The machines and processing equipment being built there use Siemens drives and controls, collaboratively integrated by Think-PLC, the automation engineering partner to Krispy Kreme.

Honestly, in my 20 years of experience, I’ve never seen an end user build such high-quality machines in-house. Krispy Kreme engineers and manufactures all of its production machines, from the extruders and conveyors through to the packaging, including its famous glaze waterfall.

Every Krispy Kreme store is a high-tech doughnut manufacturing facility. The speed at which an extruded doughnut moves through the store is a very, very big deal. Throughout the process, the shortening is kept within an exact range of temperature, monitored with a 3-inch-long Pt100 resistance temperature detector (RTD) custom supplied by Think-PLC. We use the RTD inputs on the Siemens Simatic ET 200SP remote I/O module.

The RTD signal is processed through the Profinet I/O near the fryer. It’s filtered, scaled and manipulated for multiple temperature-type displays, including European and North American units, on the Siemens TP1200 Comfort Panel on the doughnut line.

Doughnuts are cooked on both sides for a precise number of seconds on each side. The cooling conveyor cycles through the store at a set number of minutes.

Patrick Betson is Krispy Kreme’s director of equipment manufacturing. Responsible for the machine-building side of the business, he has long understood the connection between the making of great machines and the making of great doughnuts. Having gathered insights from the company’s service technicians, store managers and customers, he had initiated a range of improvements leading to increased uptime and mean time between failure.

Now those early strides pointed to the need for the latest drive technology, related software conversions and safety integration.

“Before there was much publicity about Industry 4.0 and IoT, Bobby Cole and I often talked about the data that could be generated by more advanced machine monitoring,” says Betson (Figure 1). “It became increasingly clear that, by integrating the latest Siemens drives and controls on our machines and connecting them using Profinet communications, we could start putting that data to work.”

Perfect integration

Figure 1: The integration of the drive is essential to the retrofit strategy developed by Patrick Betson (left), Krispy Kreme’s director of equipment manufacturing, and Bobby Cole, president of automation consultancy Think PLC.

Krispy Kreme’s decision to use Siemens control automation would support an aggressive rollout of new stores and the swift retrofitting of existing stores. Integrating the latest Siemens variable-frequency-drive (VFD) technology was an easy decision. The hard part would be to figure out how to conduct those retrofits in the shortest and most cost-efficient way in more than 600 stores worldwide.

A notice came from Siemens’ supply chain that product cancellation was nearing for the original Micromaster drives, which had always been standard on the doughnut line. I informed my customer Patrick Betson that we needed to have contingency plans in place. In that conversation, there was much discussion regarding the ease of install, ease of cost and ease of support, as this could be a literal show-stopper if we didn’t have our ducks in a row.

That’s when Betson and I came up with the idea of a retrofit kit, one that would enable every store to quickly add new components and software to existing hardware, making massive technology conversion acceptable to all and therefore actionable in short order (Table 1).

Retrofit kit

Table 1: The retrofit kit enables every store to quickly add new components and software to existing hardware, making massive technology conversion acceptable to all and therefore actionable in short order

Kits for rapid retrofitting

The concept of a kit was inspired by the realization that, while the Siemens drives and controls installed around 2001 were now starting to show their age, they all shared a farsighted onboard feature: an SD card. This would prove to be a time-saving, cost-cutting advantage, because the SD cards in the older Siemens drives and PLCs have been maintained to match each store’s unique set of machining and processing parameters.

In addition, each kit would include all that was needed for a local contractor to upgrade the legacy control panels, including parts for safety and power wiring. A bill of material having 15 parts would be reduced to seven. This would mean fewer parts to wear, troubleshoot and stock in the future.

The main purpose of the kit was to replace the older Siemens Micromaster drives with their Sinamics G120 drives (Figure 2). The SD card in the kit has software that we modified, and, with a couple flips of some switches, the drive is automatically programmed. Someone with absolutely no control experience can reload the new software into the new drives and the new PLCs.

Shop-floor automation

Figure 2: John Priddy, Krispy Kreme fabrication manager, installs the newly developed kit into the fryer section of a doughnut machine.

There are two systems most commonly built. The larger doughnut line used an S7-300, which has migrated to the S7-1500. The smaller lines used to have the S7-200, and they were migrated in 2010 to the S7-1200.

The newly designed S7-1500 system integrates fail-safe features—safety—into the processor. This allows for Profisafe safety to be achieved within the topology network of drives and remote I/O. Safety can now be distributed through fieldbus instead of the costly and timely install manor of hardwired signals to complex safety relays.

To prove the retrofit kit concept, we tested the kit’s installation and use in the Krispy Kreme manufacturing plant in Winston Salem, North Carolina, followed by tests at various stores in the region. The new drives and PLCs installed smoothly. Their SD cards automatically updated and matched all previous store parameters. After two months, the stores reported the trial a success. But to further test the concept themselves, we made a whirlwind trip to retrofit every store in Australia over five days using the kits (Figure 3).

Retrofit heroes

Figure 3: Retrofitting with ease—Betson and Cole found that they could retrofit every store in Australia in five days by using their technology retrofit kit concept.

The retrofit kit concept had worked. It enables a store to replace its drives and controls in about two hours. This compared to the hours invoiced by a control technician to travel to a Krispy Kreme store to do the same—a time/cost difference that would be even greater, were the SD card not a feature of the Siemens drives and PLCs.

During the doughnut frying process, the efficient pumping of heated shortening is critical to maintaining optimal doughnut quality and product count. When the flow rate is not at the desired constant, the wide range of viscosity becomes a problem. The melted shortening will not be filtered of dough bits and pieces. Temperature variances will soon occur, causing hot spots at any point in the frying process, including inside the fryer vat itself.

Behind the scenes, the Siemens Sinamics G120 drive addresses all of these pump motor concerns, while visually reporting the operational status of each motor. Moreover, the drive is working to assure that all of the pump motors are keeping their cool, below the threshold for heat damage.

In many pumping applications, motor overheating is probably the number-one service issue. That problem is being removed by the drive’s ability to set and hold a curve that assures the most efficient flow, at a low speed and at a high speed, from 7 Hz to 90 Hz. The accuracy of the fry time is also being increased by 12%, resulting in a more consistent product with less waste yield.

A big advantage of the drive is that it can run a motor slowly without the usual rise in motor temperature. When you run a motor at very low Hertz, it generates a lot of eddy current. It gets so hot, that you can’t touch the motor. And when you overheat the laminations of a motor, you greatly decrease the life of the motor. But we can monitor each drive through the Siemens TIA (Totally Integrated Automation) portal. We’ve seen the amperage reduced by almost 17%, and the temperature of the motor reduced by 34%. We expect this will more than double the life expectancy of every pump.

Remote monitoring

The successful grand opening of the Krispy Kreme store in New York’s Times Square was not without the occasional behind-the-scenes drama for new store commissioning (Figure 4). A sudden pumping issue, it was the kind of problem that can happen at any hour, at any of the 500-plus global stores owned by the company. But it is also a concern that can be quickly solved on-site or from thousands of miles away.

Shop-floor store

Figure 4: The new Krispy Kreme store in New York’s Times Square features a vertical cooling conveyor that was engineered and built by the company entirely in-house. Control integration was provided by Think PLC automation consultants using Siemens drives and controls.

The situation was addressed in a matter of minutes. I just went online through the Siemens secure TIA portal to see what the Siemens G120 drive was showing me. While setting up one of the machines, a motor had been miswired. I could quickly tell the local setup contractor where to look.

The TIA portal experience is like standing in the store at the drive’s operator interface (Figure 5). When you open the door to the drive, a large display presents any fault messages. Select a fault message and you are given the related fault code that you would in the past need to look up in the user’s manual. Now, all of the information you need—the details, what to check, how to reset—are on the display. Diagnostic screens help you debug the problem. And beyond this, faults and alarms can be data-logged in the cloud. Trends can be studied over the course of a year. Faults for a particular machine can be identified and addressed. A shortening pump that is tripping more often can be replaced during the store’s next on-site inspection.

Shorten the adoption curve

Figure 5: A store can produce a thousand dozen doughnuts per hour. Pump motor drive performance in the store can be seen through the Siemens TIA portal to diagnose, troubleshoot, maintain and prevent disruptions to production flow.

Safety integration

Krispy Kreme employees are trained and dedicated to serving up the fresh-made doughnuts that flow from their store’s unique production floor. So, if you are a Krispy Kreme employee, you do not need to understand what 60 Hz means. You are not thinking about the cylinders that are extruding the dough, the 100-plus feet of chain that is carrying the dough from the extruder to the fryer, the humidity of the dough for that particular doughnut and the exact amount of time that doughnut spends in the fryer. You see an operator interface that shows the image of a doughnut type. Press the button, and you see an hourglass representing the doughnut is in the fryer. That’s it. You can go back to serving your customers. Behind the scenes, the humidity of the dough, the temperature of the oil, the speed of doughnut flow and the frying time are all automatically being taken care of.

And all of that is being done with your safety in mind. The Sinamics G120 drive supports the design of machines and processes that have triple-quadruple redundancy. Especially in areas where the fryer is exposed, employee safety is being reinforced. The new drives and PLCs being retrofitted into every store integrate with the existing Siemens safety monitoring circuitry, inclusive of automated safety mechanisms and e-stop buttons. For example, if a hose were to break on the shortening pump, the flow stops within 100 milliseconds.

The Siemens safety circuitry is less complex and more integrated from feedback to operator standpoint, in "lieu" of a general e-stop active alarm. By incorporating ProfiSafe, we eliminated complex wiring, power contactor devices and hidden alarm messages.

Portal to the future

Betson sees the big picture that is being made clear by the data now starting to flow through the Siemens TIA portal. Along with the ability to remotely use each store’s data to plan for machine maintenance and prevention, the data can routinely be studied to measure and improve the design of the company’s machines and processes.

The remote connectivity piece is very innovative in the sense we needed to support such a large customer as Krispy Kreme all over the world. We brought the world of IoT to a valued customer before it was a buzzword. With that, Think-PLC added value in experience, leading the way into the 21st century.

Having anticipated the emergence of Industry 4.0 and IoT, Betson now also sees how data can be used to guide employee training and best practices for human-machine interaction. Continuous improvement and operational excellence can be studiously amplified storewide and in stores worldwide.

“The data we are capturing now and hereafter strengthens us in many ways,” Betson says. “It’s important to us as a machine builder, because it also reinforces our culture and Krispy Kreme’s identity in our global marketplace.”

Light the way

At the end of the day, we do these magical things. From a safety perspective, from the standpoints of reliability and the simplicity of an operator interface, the Krispy Kreme equipment group in Winston-Salem are amazing machine builders. At any hour, including when a store’s hot light is on to signal free doughnut samples are now available, or when a store is giving away free doughnuts to healthcare workers, you can’t have a machine go down, disrupting what you promise.

That ethic has come naturally to a company that has always understood the connection between making great machines and making great doughnuts.

About the author: Bobby Cole
Bobby Cole is president of Think-PLC in Winston-Salem, North Carolina. Contact him at [email protected].
